132x32 Graphic LCD Module
Description
132x32 Graphic LCD, RoHS Compliant, White Edge LED Backlight, FSTNPositive, white-black, Transflective -20°C to +80°C 6:00.
Available in several variations of backlight and polarizer (minimum order may be required).
OLED Details
132x32 Graphic LCD Module | |
Size | 1.9” |
SSD1331 | ST7567A |
Resolution | 132*32 |
Panel Size | 52*21 (mm) |
Active Area | 43.54*9.58 (mm) |
Interface | SPI |
Display Color | White-Black |
Operating Temperature | -40 to + 80 |
Operating Voltage | 3.3V |
Module Weight | TBD |
MOQ | 1 Piece |
RoHS | YES |
Please contact me for questions regarding this product. | |
Image Details
OLED Applications
-Meter
-Ammeter
-Instrument tuner
-External hard disk
- Printers
-Wearable devices
-Medical & health equipment
-3D & Shutter
Physical Size
FAQ
+How to place an order ?
Please send us your purchase order by Email or through Whats APP directly, or ask us to send you one invoice.
+How can I get the data sheet ?
If you need the standard OLED, the datasheet will be sent to request after getting your inquiry.
+How long can I get the sample?
Samples will be ready for deliver in 5-7 days.
